CT Series Top Mount Sand Filter

PRODUCTS > THE SAND FILTER > CT Series Top Mount Sand Filter

CT Series Top Mount Sand Filter

Multy-valve is made of import ABS material,increased the elasticity, tensile strength and heat resistance, corrosion resistance,and the surface is smooth, good brightness, high hardness.Fiberglass sand filters are manufactured using high quality unsaturated polyester resin, good elasticity and strong corrosion resistance,fiberglass winding reinforced filter tank stronger,combined with handwork and import resin、fiber,spray gun injection production,sturdy and durable,higher production efficiency.The surface spray heavy duty UV protective layer after the overall filament winding,Beautiful,durable, strong UV protection ability,it can.be used for a long time in different work and climate environment.


ATTENTIONS

Turn off the water pump power before convert any function on the multy-valve,the temperature of the circulating water up to 50C (122°F).
Sand filter maximum working pressure:2 .5Kg(250Kpa/36psi/2. 5bar),the maximum pressure test is 4Kg(400Kpa/58psi/4 0bar).Can be produced according to specify different color, different
degree of pressure.The maximum operating temperature is: 50°C (122°F).
The coarse silica sand specification is 0.5mm-0. 8mm,Fine sand specifications is: 1mm-2 mm.
