CPS Side Mount Sand Filter With Pump Combo

Sand Filter With Pump Combo ,which equipped top mount or side mount filter and corresponding matching filter pump self-priming cycle,drug delivery device is optional,easy to handle,easy to operate,save a space,strong and durable,Greatly improve the comprehensive performance and efficiency.resulting more customers select it for their swimming pools,fishpond and landscape pool.


ATTENTIONS

Turn off the water pump power before convert any function on the multy-valve,the temperature of the circulating water up to 50°C (122°F).Sand filter maximum working pressure:2.5Kg(250Kpa/36psi/2.5bar),the maximum pressure test is 4Kg(400Kpa/58psi/4 .0bar).The maximum operating emperature is: 50°C(122°F).

The coarse silica sand specification is 0.5mm-0 8mm,Fine sand specifications is: 1mm-2 mm.Inside the tank body can fill fiter material,soften the resin particles or activated carbon. Because of the differences in quartz sand specification in different regions, sand weight data are just for reference.The filter material not more than two-thirds of the sand tank volume,at least 20 cm below the water bucket.Transparent conducting sand filter plate in place before fll with the filter material,to prevent the filter material into the inside base pipe of the sand filter.
